Engine
Engine Type: 4-Stroke, 4-Valve, eSP+
Displacement: 156.9 cc
Cooling System: Liquid Cooled
Fuel Supply System: PGM-FI (Programmed Fuel Injection)
Bore x Stroke: 60 x 55.5 mm
Compression Ratio: 12:1
Transmission Type: Automatic, V-Matic
Maximum Power: 11.3 kW (15.4 PS) / 8,500 rpm
Maximum Torque: 13.8 Nm (1.5 kgf·m) / 7,000 rpm
Clutch: Automatic Centrifugal, Dry Type
Starter: Electric
Engine Oil Capacity: 0.8 liter (periodic replacement)

Frame
Frame Type: Underbone – eSAF (enhanced Smart Architecture Frame)
Front Suspension: Telescopic
Rear Suspension: Swing Arm with Single Suspension
Front Tire Size: 110/90 – 12 M/C Tubeless
Rear Tire Size: 130/80 – 12 M/C Tubeless
Front Brake:
220 mm Hydraulic Disc (ABS)
190 mm Hydraulic Disc (CBS)
Rear Brake: 220 mm Hydraulic Disc (ABS) & Drum Brake (CBS)

Dimensions
L x W x H:
1,886 x 706 x 1,133 mm (ABS)
1,886 x 701 x 1,133 mm (CBS)
Seat Height: 768 mm
Wheelbase: 1,275 mm
Ground Clearance: 151 mm
Curb Weight: 115 kg (CBS) & 118 kg (ABS)

Electrical
Ignition System: Full Transistorized
Battery Type: MF 12V–5 Ah
Spark Plug Type: NGK LMAR8L-9
