Power
Maximum Power: 8.6 kW (12 PS) @ 8,000 rpm
Maximum Torque: 11.3 Nm (1.2 kgfm) @ 6,500 rpm
Engine Type: Air-cooled, 4-stroke, single-cylinder
Displacement: 144 cc
Bore x Stroke: 58.0 mm x 54.4 mm
Compression Ratio: 9.5:1
Valve System: SOHC, 2 valves
Fuel Supply System: Carburettor: Keihin NCV24
Ignition System: DC-CDI
Starter: Electric
Transmission: 5-speed, return
Primary Reduction Ratio: 2.880 (72/25)
Final Reduction Ratio: 3.214 (45/14)
Clutch: Wet multi-disc, manual
Final Drive System: Chain

Performance
Frame Type: Perimeter, steel
Front Suspension: ø35 mm inverted fork
Rear Suspension: Uni-Trak, single shock with adjustable spring preload
Front Wheel Travel: 175 mm
Rear Wheel Travel: 192 mm
Rake / Trail: 26.4° / 91 mm
Front Tire: 100/80-17M/C 52P
Rear Tire: 120/70-17M/C 58P
Front Brake: Semi-floating ø300 mm petal disc
Front Caliper: Twin-piston
Rear Brake: ø220 mm petal disc
Rear Caliper: Single-piston

Dimensions
Length x Width x Height: 1,995 x 960 x 1,165 mm
Wheelbase: 1,335 mm
Ground Clearance: 270 mm
Seat Height: 840 mm
Curb Weight: 120 kg
Fuel Tank Capacity: 6.9 liters
