Engine

Engine Type: 4-Stroke, 2-Valve SOHC, Air-Cooled, Blue Core
Cylinder Arrangement: Single Cylinder
Bore x Stroke: 52.4 x 57.9 mm
Compression Ratio: 9.5 : 1
Displacement: 125 cc
Maximum Power: 7.0 kW / 8000 rpm
Maximum Torque: 9.6 N·m / 5500 rpm
Starting System: Electric Starter and Kick Starter
Lubrication System: Wet Sump
Engine Oil Capacity:
Total: 0.84 L
Periodic Change: 0.80 L
With Oil Filter Replacement: 0.80 L
Fuel Supply System: Fuel Injection (FI)
Clutch Type: Dry Centrifugal, Automatic
Transmission Type: V-Belt Automatic

Frame
Front Tire: 80/80-14MC 43P, Tubeless
Rear Tire: 100/70-14MC 51P, Tubeless
Front Brake: Single Disc Brake
Rear Brake: Drum Brake
Rear Suspension: Unit Swing
Frame Type: Underbone
Front Suspension: Telescopic

Dimension
L x W x H: 1,860 mm x 740 mm x 1,070 mm
Wheelbase: 1,260 mm
Ground Clearance: 135 mm
Seat Height: 760 mm
Curb Weight: 98 kg
Fuel Tank Capacity: 4.2 L

Electricity
Ignition System: TCI (Transistor Controlled Ignition)
Battery Type: YTZ4V / GTZ4V
Spark Plug Type: NGK / CR6HSA
